Weifang U-one Machinery Equipment co.,ltd specializes in designing, manufacturing and installing of ventilation equipment.
Products Description
【Performance characteristics】:
◆Special greenhouse motor with national standard, high efficiency and energy saving. Running smoothly in high temperature and humidity circumstance
◆Passed 360 hours laboratory destructive testing, excellent performance
◆The blades are made of light aluminum punching in one time, has the features of large angle, big wind capacity, light proportion, low noise, corrosive resistance. The fan with a special motor is energy saving, large air volume, long air throw distance. 30% energy saving compared with the other similar products.
◆The shell adopts advanced current collector, made from stainless steel 304. The fan with refined bright appearance processed by CNC stamping.
◆Front and rear safety nets, beautiful and safe.
◆Hanging fasteners made of stainless steel, the angle can be adjusted and easy installation
◆The circulation fan with international standard ISO(9001:2008) certificate
◆International advanced energy saving and thermal protection technology, more than 12 years service time.
◆Run smoothly, stable wind, no shake, low noise.
【Technical parameters 】:
Model | Blades Diameter (mm) | Blades | Motor Run
Speed (rpm) |
Air flow (m3/h) | Power
(W) |
Voltage
(V) |
Material | Size(mm) |
UOA-300-1 | 285
|
4 | 1400 | 2800 | 120 | 220/380 | SS304 | 360*360*260 |
UOA-300-2 | 285 | 4 | 1400 | 2800 | 120 | 220/380 | Galvanized sheet | 360*360*260 |
UOA-400-1 | 385 | 4 | 1400 | 3800 | 120 | 220/380 | Galvanized sheet | 460*460*270 |
UOA-400-2 | 385 | 4 | 1400 | 3800 | 120 | 220/380 | SS201 | 455*455*310 |
UOA-400-3 | 385 | 7/4 | 1400 | 3800/4500 | 120/180 | 220/380 | SS304 | 460*460*270 |
UOA-500-1 | 485 | 5 | 1400 | 5500 | 180 | 220/380 | Galvanized sheet | 560*560*270 |
UOA-500-2 | 485 | 5 | 1400 | 5500 | 180 | 220/380 | SS201 | 555*555*310 |
UOA-500-3 | 485 | 5/7 | 1400 | 5500/8800 | 180/370 | 220/380 | SS304 | 565*565*270/300 |
UOA-600-1 | 585 | 7 | 1400 | 15000 | 1500 | 380 | SS304 | 680*680*400 |
UOA-600-2 | 585 | 7 | 1400 | 15000 | 1500 | 220 | Galvanized sheet | 680*680*400 |
